Part Information

Name: Radiator

Part No.: CT-BM009

Remark:

Depth (mm):32

Length (mm):650

Transmission ():MT

Width (mm):438

OEM Number

BMW 17111702969

BMW 17111737711

BMW 17101742099

Buyers Guide

Model	Engine	Displacement	Power	Hp	Year
BMW_7 (E38)					199410-200111
7 (E38) 730 i,iL	M60 B30	2997	155	211	199410-200111
7 (E38) 730 i,iL	M60 B30	2997	160	218	199410-200111
7 (E38) 740 i,iL	M60 B40	3982	210	286	199410-200111
7 (E38) 750 i,iL	M73 B54	5379	240	326	199412-200111
7 (E38) 740 i,iL	M62 B44M62 448 S2M62 B44 TU	4398	210	286	199601-200111
7 (E38) 728 i,iL	M52 B28 TUM52 B28	2793	142	193	199508-200111
7 (E38) 735 i,iL	M62 B(35 8 S1)M62 B35	3498	173	235	199601-200111
BMW_5 (E39)					199511-200306
5 (E39) 525 tds	M51 D25 (Inter.)	2503	105	143	199601-200306
5 (E39) 528 i	M52 B28M52 B28 TU	2793	142	193	199511-200009
5 (E39) 540 i	M62 B44M62 448 S2M62 B44 TU	4398	210	286	199604-200306
5 (E39) 535 i	M62 B(35 8 S1)M62 B35	3498	173	235	199604-199903
BMW_5 Touring (E39)					199701-200405
5 Touring (E39) 520 i	M52 B(20 6 S3) VanosM52 B(20 6 S4)M52 B20	1991	110	150	199701-200009
5 Touring (E39) 523 i	M52 B25 TUM52 B25 (Vanos)	2494	125	170	199701-200009
5 Touring (E39) 540 i	M62 B44M62 448 S2M62 B44 TU	4398	210	286	199701-200405
5 Touring (E39) 528 i	M52 B28M52 B28 TU	2793	142	193	199701-200009
5 Touring (E39) 525 tds	M51 D25 (Inter.)	2503	105	143	199703-200405
